Products
Every product is made to your specified thickness, dual-ply as standard, from 100% imported virgin fibre under de-mineralised process conditions, and tested batch by batch against IS 8570 / IEC 60554.
| Product | Thickness range (tailor-made) | Width | Compliance | Applications |
|---|---|---|---|---|
| Electrical Grade Insulation Kraft Paper | 1.5 mil to 10 mil | Up to 2500 mm | IS 8570 / IEC 60554 | Transformer interleaving, Conductor covering, Conductor winding and covering, Bushings, Distribution transformers, Power transformers |
| High Density Kraft Paper | 3 mil to 10 mil | Up to 2500 mm | IS 8570 / IEC 60554 | Transformer interleaving, Bushings, Distribution transformers, Power transformers |
| Diamond Dotted Paper (DDP) | 3 mil to 10 mil | Up to 2500 mm | IEC 60554 | Insulation between coils in oil-immersed transformers, Cable insulation |
| Diamond Dotted Paper HD (DDP-HD) | 3 mil to 10 mil | Up to 2500 mm | IS 8570 / IEC 60554 | Insulation between coils in oil-immersed transformers |
Insulation kraft paper in a thickness range of 1.5 mil to 10 mil, made to your specified thickness from 100% imported virgin fibre under de-mineralised process conditions.
Full specifications: Electrical Grade Insulation Kraft Paper
High density electrical grade insulation kraft paper in a thickness range of 3 mil to 10 mil, made to your specified thickness for applications that call for higher density.
Electrical insulating paper from 3 mil to 10 mil, coated with heat-curable epoxy resin, for oil-immersed transformer coil insulation.
Diamond Dotted Paper on a high density base, 3 mil to 10 mil, coated with heat-curable epoxy resin for oil-immersed transformer coil insulation.
Tell us thickness, width and volume, and we quote against your specification.
Request a Quote
